Fisher & Paykel RS7621SRHE1 Fridge Integrated
The Fisher & Paykel RS7621SRHE1 is a 76cm integrated column refrigerator offering advanced ActiveSmart™ technology, flexible storage, and a sleek, seamless design—perfect for modern kitchens seeking premium food care and style.
€12.999,00
Description
Functions & specifications
61,0 × 75,6 × 213,4 cm (L×W×H)
133,0 kg
Functions
App‑name
SmartHQ
Wi‑Fi
Yes (Smart & Connected)
Compatible Operative System
N/A
Energy smart
ActiveSmart™ Foodcare
0‑zone
N/A
Door alarm
Yes
Air circulation
Yes
NoFrost
Yes (Frost free)
Freshness technologies
ActiveSmart™ Foodcare, Humidity control system, Variable Temperature Zones
Voice control
N/A
Separate on/off button for fridge/freezer
N/A
Voice control compatible with
N/A
Child safety
N/A
Lock on door
N/A
Design and placing
Charcoal filter
N/A
Compressor type
Inverter controlled compressor
No. Of compressors
1
Control panel
Yes
Display type
Electronic
Placing of display
Center
Display color
White
Temperature control
Variable Temperature Zones (Pantry; Fridge; Chill)
Temperature display
Yes
Door panel decor
Panel Ready
Type of lights
LED bin lighting; LED ceiling lighting; LED side lighting
Moist control in the vegetable drawer
Yes (Humidity control system)
Vegetable drawer
N/A
Fixed water supply to ice machine
Integrated water system (internal water dispenser)
Max no. of bottles/cans
Stackable bottle holders 4
Temperature zone
2 Variable Temperature Zones
Thermostat type
Electronic
Water/ice dispenser
Internal water dispenser
No. of 0‑zone drawers
N/A
No. of bottle shelves
N/A
No. of baskets for the freezer
N/A
No. of glass shelves
Adjustable glass shelves 3
No. of vegetable drawers
N/A
No. of plastic shelves
Adjustable door shelves 4
No. of shelves in the freezer
N/A
No. of steel shelves
N/A
No. of wooden shelves
N/A
Inner camera (accessories)
N/A
No. of stars (*) freezer
N/A
Climate class
N/A
Lowest suitable room temperature (°C)
10
Highest suitable surrounding temperature (°C)
43
Door mounted
Door-On-Door
Reversable doors
Yes
Door
Panel Ready
Door hinges
Right hanging
Soft close on door
N/A
Type of handle
Optional handle kits (sold separately)
Depth incl. door handle
610 mm
UV‑protected door
N/A
Wheels
N/A
Adjustable feet
Front‑adjustable levelling feet
Place side by side
Yes (pair with other columns)
Sidewall heating
N/A
Soft close on vegetable drawer
Yes
No. of telescopic rails
N/A
Type of telescopic rails
N/A
Capacity and consumption
Plug type
EU plug
Cable length (cm)
N/A
Cable mounted
Yes
Nominal frequency 50/60 Hz
50 Hz
Connected power (A)
Rated current 10 A
Rated voltage (V)
Supply voltage 230 V
Energy class
4‑tick energy rating
Energy consumption year (kWh)
N/A (guide gives kWh for similar variants)
Cooling volume (L)
Total volume 463 L / Refrigerator volume 463 L
Freezing volume net (l)
N/A
Noise level (dB)
35
Noise emission class dB(A)
N/A
Total display area (m²)
N/A
Highest temperature with chilled operating temperatures (°C)
Pantry mode 11–13 °C
Lowest temperature with chilled operating temperatures
N/A
Energy efficiency index (EEI)
N/A
Built‑in size (HxWxD) mm
Height 2134 mm; Width 756 mm; Depth 610 mm
Freezing volume gross (l)
N/A
Freezing capacity (kg/24h)
N/A
Coolant type
N/A
Coolant type weight (g)
N/A
Storage time in the event of power failure (hours)
N/A
Requires technician
Yes
Product data & user manual
Product data
Brand:
Fisher & Paykel
SKU: 100001651
EAN: 9415112269275
Content in the box
Fisher & Paykel RS7621SRHE1 Fridge Integrated
€12.999,00
Fisher & Paykel Series 11
Columns that blend into the kitchen
Integrated column refrigerators and freezers, 213 cm tall and 46, 61 or 76 cm wide. Install one on its own or pair them, behind door panels that match your kitchen.
The numbers
213cm
Full-height columns for a 213.4 cm high niche.
3
Widths: 46 and 61 cm freezers, 61 and 76 cm refrigerators.
2
Variable Temperature Zones in every column, each with its own setting.
76 cm wideColumn refrigerator
RS7621SRHE1
The 76 cm column refrigerator, with a water dispenser inside and two Variable Temperature Zones. It reaches energy class B.
- Volume472 l
- Variable zones2 · Fridge, Pantry or Chill
- Size (H × W × D)213.4 × 75.6 × 61 cm
- Niche (H × W × D)213.4 × 76.2 × 63.5 cm or more
- Water and iceInternal water dispenser
- HingeRight
- Joiner kitSold separately
- Energy classB · 103 kWh a year
- Noise level35 dB · class B
61 cm wideColumn refrigerator
RS6121SRHE1
The 61 cm column refrigerator, with a water dispenser inside, two Variable Temperature Zones and soft-close fruit and vegetable bins.
- Volume358 l
- Variable zones2 · Fridge, Pantry or Chill
- Size (H × W × D)213.4 × 60.3 × 61 cm
- Niche (H × W × D)213.4 × 60.9 × 63.5 cm or more
- Water and iceInternal water dispenser
- HingeRight
- Joiner kitSold separately
- Energy classC · 104 kWh a year
- Noise level35 dB · class B
61 cm wideColumn freezer
RS6121FLJE1
The 61 cm column freezer, with an automatic ice maker, two Variable Temperature Zones down to Deep Freeze at -25 °C, and controls at counter height.
- Volume355 l
- Variable zones2 · Soft Freeze, Freezer or Deep Freeze
- Size (H × W × D)213.4 × 60.3 × 61 cm
- Niche (H × W × D)213.4 × 60.9 × 63.5 cm or more
- Water and iceAutomatic ice maker
- HingeLeft
- Joiner kitIncluded (AJ-RS21LR)
- Energy classE · 274 kWh a year
- Noise level41 dB · class C
46 cm wideColumn freezer
RS4621FLJE1
The slim 46 cm column freezer, with an automatic ice maker, two Variable Temperature Zones down to Deep Freeze at -25 °C, and controls at counter height.
- Volume234 l
- Variable zones2 · Soft Freeze, Freezer or Deep Freeze
- Size (H × W × D)213.4 × 45.1 × 61 cm
- Niche (H × W × D)213.4 × 45.7 × 63.5 cm or more
- Water and iceAutomatic ice maker
- HingeLeft
- Joiner kitIncluded (AJ-RS21LR)
- Energy classE · 244 kWh a year
- Noise level40 dB · class C
46 cm wideColumn freezer
RS4621FLJK2
A 46 cm column freezer with an automatic ice maker, Ice Boost and two Variable Temperature Zones down to Deep Freeze at -25 °C.
- Volume220 l
- Size (H × W × D)213.4 × 45.1 × 61 cm
- Water and iceAutomatic ice maker
- HingeLeft
- Joiner kitIncluded (AJ-RS21LR)
- Energy classE · 235 kWh a year
- Noise level42 dB · class D
Figures from Fisher & Paykel's quick reference guide for this model.
Mix & Match
Build your own wall
Choose the sizes you need and install them separately or side by side. The refrigerators are hinged on the right and the freezers on the left, so a freezer placed to the left of a refrigerator opens away from it.
These columns fit flush, with only 3 mm gaps and no visible hinges or grilles. Hidden behind your own cabinet doors, they give the kitchen a calm, uninterrupted front.
These columns fit flush, with only 3 mm gaps and no visible hinges or grilles. Hidden behind your own cabinet doors, they give the kitchen a calm, uninterrupted front.
These columns fit flush, with only 3 mm gaps and no visible hinges or grilles. Hidden behind your own cabinet doors, they give the kitchen a calm, uninterrupted front.
These columns fit flush, with only 3 mm gaps and no visible hinges or grilles. Hidden behind your own cabinet doors, they give the kitchen a calm, uninterrupted front.
Fisher & Paykel's 61 cm Series 11 wine column belongs to the same collection, so you can add a wine cabinet to the row.
Door panels and handles are sold separately. Use your own cabinet doors or Fisher & Paykel's stainless steel door panels.
Variable Temperature Zones
One temperature doesn't fit all. Each column has two compartments that you switch to the climate your food and drinks need.
1 of 3
Refrigerator zones
In RS7621SRHE1 and RS6121SRHE1 both compartments are Variable Temperature Zones. The upper one switches between Fridge and Pantry, the lower one between Fridge, Pantry and Chill.
Fridge keeps 1 to 6 °C for everyday food, and Chill -1.5 to 0 °C. Switch a compartment for everyday convenience, or to get extra capacity when you need it.
2 of 3
Pantry Mode
Not everything benefits from cold storage. Pantry Mode (11 to 13 °C) is the cool, dark place for bread, many types of fruit, bananas, avocados, tomatoes, nuts, grains and cereals.
It is available in both compartments of the column refrigerators.
3 of 3
Soft Freeze to Deep Freeze
In the freezers, switch a compartment to Soft Freeze for everyday convenience, or choose Freezer or Deep Freeze to keep food longer.
Deep Freeze (-25 °C) halts bacterial activity, so food can be stored safely for longer periods. In RS6121FLJE1 and RS4621FLJE1, Soft Freeze holds -10 to -8 °C and Freezer -21 to -14 °C.
Premium interior
As good inside as it looks outside
Series 11 columns have a premium interior with a sleek, understated look the moment you open the door.
LED lights in the ceiling, on the sides and in the bins make it easy to find what you are looking for.
The details
Ice & water
Built in, out of sight
The freezers have an automatic ice maker with Ice Boost for busy times. The refrigerators have a water dispenser inside. All of them need a water connection.
Clever energy
Only the energy it needs
ActiveSmart™ Foodcare adapts to how you use the column. RS7621SRHE1, RS6121SRHE1, RS6121FLJE1 and RS4621FLJE1 also have highly efficient vacuum insulation that reduces heat transfer.
Easy install
Slides into place
Every column has front-adjustable levelling feet and slides into place as a separate unit, so a single column or a whole row is easy to install.
Questions and answers
What niche does it need?
A niche 213.4 cm high, 76.2 cm wide and at least 63.5 cm deep (65 cm if the connections are at the back of the niche), based on 19 mm door panels.
A niche 213.4 cm high, 60.9 cm wide and at least 63.5 cm deep (65 cm if the connections are at the back of the niche), based on 19 mm door panels.
A niche 213.4 cm high, 60.9 cm wide and at least 63.5 cm deep (65 cm if the connections are at the back of the niche), based on 19 mm door panels.
A niche 213.4 cm high, 45.7 cm wide and at least 63.5 cm deep (65 cm if the connections are at the back of the niche), based on 19 mm door panels.
The cabinet must be at least 213.4 cm high inside, 45.7 cm wide inside the frame and 63.5 cm deep.
Is the door panel included?
No. Fit a door panel that matches your kitchen, or Fisher & Paykel's stainless steel door panel. Handles and toe kicks are also sold separately.
The panel may weigh up to 30 kg, handle included. The stainless steel panels are RD7621R10D (right hinge) and RD7621L10D (left hinge).
The panel may weigh up to 25 kg, handle included. The stainless steel panels are RD6121R10D (right hinge) and RD6121L10D (left hinge).
The panel may weigh up to 25 kg, handle included. The stainless steel panels are RD6121L10D (left hinge) and RD6121R10D (right hinge).
The panel may weigh up to 20 kg, handle included. The stainless steel panels are RD4621L10D (left hinge) and RD4621R10D (right hinge).
The stainless steel panels are RD4621L10D (left hinge) and RD4621R10D (right hinge).
Can I change the hinge side?
The refrigerators come hinged on the right and the freezers on the left.
Changing the side needs a hinge change kit, which is sold separately.
Changing the side needs a hinge change kit, which is sold separately.
Changing the side needs a hinge change kit, which is sold separately.
Changing the side needs a hinge change kit, which is sold separately.
Do I need a joiner kit?
Only if you install two columns side by side. The joiner kit is AJ-RS21LR.
Not when you pair this refrigerator with a column freezer, because the freezers come with one. Next to another column refrigerator, buy the joiner kit separately.
Not when you pair this refrigerator with a column freezer, because the freezers come with one. Next to another column refrigerator, buy the joiner kit separately.
It is included with this freezer.
It is included with this freezer.
It is included with this freezer.
Does it need a water connection?
Yes, for the internal water dispenser. It uses water filter 847200, and the connection can be in a cabinet next to it.
Yes, for the internal water dispenser. It uses water filter 847200, and the connection can be in a cabinet next to it.
Yes, for the ice maker. It uses water filter 847200, and the connection can be in a cabinet next to it.
Yes, for the ice maker. It uses water filter 847200, and the connection can be in a cabinet next to it.
Yes, for the ice maker. It uses water filter 847200.
Can I control it from my phone?
It is a smart appliance with Wi-Fi.
Over Wi-Fi you get remote operation, alerts and notifications, and software updates.
Over Wi-Fi you get remote operation, alerts and notifications, and software updates.
Over Wi-Fi you get remote operation, alerts and notifications, and software updates.
Over Wi-Fi you get remote operation, alerts and notifications, and software updates.
How energy efficient and quiet is it?
Energy class B with 103 kWh a year, and 35 dB, noise class B.
Energy class C with 104 kWh a year, and 35 dB, noise class B.
Energy class E with 274 kWh a year, and 41 dB, noise class C.
Energy class E with 244 kWh a year, and 40 dB, noise class C.
Energy class E with 235 kWh a year, and 42 dB, noise class D, according to Fisher & Paykel's quick reference guide.
What is the difference between RS4621FLJK2 and RS4621FLJE1?
Both are 46 cm column freezers with an automatic ice maker and two Variable Temperature Zones. For RS4621FLJE1 the EU product information sheet gives 234 litres and energy class E with 244 kWh a year. For RS4621FLJK2 only Fisher & Paykel's quick reference guide is available: 220 litres and energy class E with 235 kWh a year. The quick reference guides list the same volume, 220 litres, for both models.
The Fisher & Paykel RS7621SRHE1 is a 76cm Series 11 Integrated Column Refrigerator, designed for seamless kitchen integration. Its flush fit and customizable front panels blend effortlessly with cabinetry for a sleek, modern look.
